20
Software
Components: Only
The Giants Survive[1]
Note:
This web page was converted automatically from a Word original. There may be
problems with the formatting and the pictures. To see the intended form, follow
one of these links: Acrobat, Word.
Abstract
For many years
programmers have dreamed of building systems from a library of reusable
software components together with a little new code. The closest we’ve come is
Unix commands connected by pipes. This paper discusses the fundamental reasons
why software components of this kind have not worked in the past and are
unlikely to work in the future. Then it explains how the dream has come true in
spite of this failure, and why most people haven’t noticed.
Introduction
People have been complaining
about the “software crisis” at least since the early 1960’s. The famous NATO
software engineering conference in 1968 brought the issue into focus, and
introduced the term “software engineering”. Many people predicted that software
development would grind to a halt because of our inability to handle the
increasing complexity; of course this has not happened.
What is
often overlooked is that the software crisis will always be with us (so that it
shouldn’t be called a “crisis”). There are three reasons for this:
·
As
computing hardware becomes 100 times more powerful every decade (because of
·
Although
it’s difficult to handle complexity in software, it’s much easier to handle it
there than elsewhere in a system. A good engineer therefore moves as much
complexity as possible into software.
·
External
forces such as physical laws impose few limits on the application of computers.
Usually the only limit is our inability to write the programs. Without a theory
of software complexity, the only way to find this limit is trial and error, so
we are bound to over-reach fairly often. “A man’s reach should exceed his grasp,
or what’s a heaven for.”—Browning.
At the 1968
NATO conference, Doug McIlroy proposed that a library of software components
would make programming much easier [7]. Since then, many people have advocated
and worked on this idea; often it’s called “reusable software”, though this
term has other meanings as well. Most recently, the PITAC report [9] proposed a
major research initiative in software components. This paper explains why these
ideas won’t work.
Figure 1: A typical business application
How much
progress has there been in software in the last 40 years? Either a little or a
lot: the answer depends on what kind of software you mean.
A little,
if you are writing a self-contained program from scratch, or modifying an
existing self-contained program. The things that help the most are type-safe
languages such as Pascal and Java, and modules with clean interfaces [8]; both
have been around for 30 years. Program analysis tools help with modifications,
and they have been improving steadily [3].
A lot, if
you are doing a typical business computing application. You build your
application on top of a few very large components: an operating system (Linux
or Windows), a browser (Netscape or Internet Explorer), a relational database
and transaction processor (DB2,
The
component library: Dream and reality
McIlroy’s idea was
a large library of tested, documented components. To build your system, you
take down a couple of dozen components from the shelves and glue them together
with a modest amount of your own code.
The
outstanding success of this model is the Unix commands designed to be connected
by pipes: cat, sort, sed, and their friends [6]. There are quite a few
of these, and you can do a lot by putting them together with a small amount of
glue, usually written in the shell language. McIlroy [1] gives a striking
example. It works because the components have a very simple interface (a
character stream, perhaps parsed into lines or words) and because most of them
were written by a single tightly-knit group. Not many components have been
added by others.
Another
apparent success is the PC hardware industry. PC’s are built from (hardware)
components: processor and chipset,
For the
most part, component libraries have been a failure, in spite of much talk and a
number of attempts. There are three major reasons for this:
·
There’s
no business model.
·
It
costs a client too much to understand and use a component.
·
Components
have conflicting world views.
No business model
Design is expensive, and reusable
designs are very expensive. It costs between ˝ and 2 times as much to build a
module with a clean interface that is well-designed for your system as to just
write some code, depending on how lucky you are. But a reusable component costs
3 to 5 times as much as a good module. The extra money pays for:
·
Generality:
A reusable module must meet the needs of a fairly wide range of ‘foreign’
clients, not just of people working on the same project. Figuring out what
those needs are is hard, and designing an implementation that can meet them
efficiently enough is often hard as well.
·
Simplicity:
Foreign clients must be able to understand the interface to a module fairly
easily, or it’s no use to them. If it only needs to work in a single system, a
complicated interface is all right, because the client has much more context.
·
Customization:
To make the module general enough, it probably must be customizable, either
with some well-chosen parameters or with some kind of programmability, which
often takes the form of a special-purpose programming language.
·
Testing:
Foreign clients have higher expectations for the quality of a module, and they
use it in more different ways. The generality and customization must be tested
as well.
·
Documentation:
Foreign clients need more documentation, since they can’t come over to your
office.
·
Stability:
Foreign clients are not tied to the release cycle of a system. For them, a
module’s behaviour must remain unchanged (or upward compatible) for years,
probably for the lifetime of their system.
Regardless
of whether a reusable component is a good investment, it’s nearly impossible to
fund this kind of development. It’s not necessary for building today’s system,
and there’s no assurance that it will pay off.
It’s also
very difficult to market such components:
·
There
are many of them, so each one gets lost in the crowd.
·
Each
client needs a number of them, so they can’t be very expensive.
·
Each
one is rather specialized, so it’s hard to find potential customers.
Cost to understand
To use a
component, the client must understand its behaviour. This is not just the
functional specification, but also the resource consumption, the exceptions it raises,
its customization facilities, its bugs, and what workarounds to use when it
doesn’t behave as expected or desired. One measure of this cost is the ratio of
the size of a complete specification (which of course seldom exists) to the
size of the code. For a modest-sized component, this ratio is usually
surprisingly large.
Furthermore,
because the written spec is almost always quite inadequate, there is
uncertainty about the cost to discover the things that aren’t in the spec, and
about the cost to deal with the surprises that turn up. If the module has been
around for a while and has many satisfied users, these risks are of course
smaller, but it’s difficult to reach this happy state.
The
client’s alternative is to recode the module. Usually this is more predictable,
and problems that turn up can often be handled by changing the module rather
than by working around them. This is probably feasible if the module is built
as part of the same project, but impossible if it’s a reusable component.
Conflicting world views
The interface to a
component embodies a view of the world: data types, resource consumption,
memory allocation, exception handling, etc. If you take 10 components off the
shelf, you are putting 10 world views together, and the result will be a mess.
No one is responsible for design integrity, and only the poor client is
responsible for the whole thing working together. There can easily be n2 interactions among n components.
Good
things that aren’t reusable components
People often ask
“What about Corba and COM; aren’t they successful?” Perhaps they are, but they
are ways to run components, not components themselves. They play the role of a
linker and a calling convention for distributed computing.
The
“components” that you can get for Visual Basic, Java, Microsoft Office, and
browsers are not reusable components either. You can use a couple of them in
your system, but if you use 10 of them things will fall apart, because they are
not sufficiently robust or well-isolated. If you don’t believe this, try it for
yourself.
Nor is a
module with a clean interface a reusable component, for all the reasons
discussed above. A clean interface is a very good thing, and it’s certainly
necessary for a reusable component, but it’s not sufficient.
Platforms
The last section
shows why a public library of software components is not possible. Some less
ambitious things have worked, however. Most of them are variations on the idea
of a platform, which is a collection
of components on top of which many people can build programs, usually
application programs. Windows, Linux, Java, DB2, Microsoft Office, OpenGL, the
IMSL numerical library, and PC hardware are examples of platforms. So, on a
smaller scale, are the Unix shell and text processing commands discussed in the
introduction.
The
essential property of a platform is that someone takes responsibility for its
coherence and stability. Often this is a vendor, motivated by the fact that
having lots of application expands the market for the platform. It can also be
a community, as in the case of Linux or OpenGL, in which component builders are
motivated by status in the community or by the fact that they are also clients.
A platform needs a shared context that everyone understands and a common world
view that everyone accepts; this means that its community must include both the
component builders and many of the clients. A shared context is much easier
when the domain is narrow and there’s a clean mathematical model, as with
graphics or numerical libraries.
Sometimes
people try to build lots of components on a common and hospitable platform,
such as Visual Basic or Java. This can work if the components come from (or
pass through) a single source that takes responsibility for their coherence.
Otherwise the problems of too little generality, cost to understand, and
conflicting world views make it impossible to use more than two or three of
them in a system.
Big
components
As we saw in the
introduction, big components like browsers and database systems do work, even
though a library cannot. They are five million lines of code and up, so huge
that you only use three or four of them: Linux or Windows, Netscape or Internet
Explorer,
Business model: There’s a market for such big things. Lots of
people need each one, there are only a few of them, and the client only has to
buy a couple of them, so marketing is feasible. Building your own, on the other
hand, is not feasible, even if you only use 1% of the features: 1% of 20
million lines is still 200,000 lines of code to write, and that’s a low
estimate of the amount of code for 1% of the features.
Cost to understand: The specification may be large and
complicated, but it is much smaller than the code. Because the market is large,
vendors can afford to invest in documentation; in fact, every such component
has a mini-industry of books about it. They can also afford to invest in
customization: operating systems have applications and scripting languages,
browsers have scripts, Java, plug-ins, and dynamic HTML, and database systems
have SQL.
Conflicting world views: If you use three of them, there
are only three pairwise interactions, and only two if they are layered. The
vendor provides design integrity inside each big component.
In fact, big
components, along with transaction processing, spreadsheets, SQL, and HTML, are
one of the great successes of software in the last 20 years.
People
often complain about big components because they are wasteful. A business
application built on a browser and a database system can easily consume 100
times the resources of one that is carefully tailored to the job at hand. This
is not waste, however, but good engineering. There are plenty of hardware
resources; what’s in short supply are programmers and time to market, and
customers care much more about flexibility and total cost of ownership than
about raw hardware costs.
Another way
to look at this is that today’s PC is about 10,000 times bigger and faster than
the Xerox Alto [10], which it otherwise closely resembles. It certainly doesn’t
do 10,000 times as much, or do it 10,000 times faster. Where did the cycles go?
Most of them went into delivering lots of features quickly, which means that you
can’t have first-class design everywhere. Software developers trade hardware
resources for time to market. A lot of them also went into integration (for
example, universal character sets and typography, drag and drop, embedding
spreadsheets in text documents) and into compatibility with lots of hardware
and with lots of old systems. And a factor of 10 did go into faster responses
to the user’s actions.
What
else could work?
If
components can’t help us much to build software, what can? Two approaches are
promising: declarative programming, and specifications with teeth.
Declarative programming
“Declarative
program” is not a precise concept, but the idea is that the program is close to
the specification, perhaps even the same. For example, in a simple spreadsheet
the program is just the formulas; if there is no higher structure, the formulas
express the user’s intent as simply as possible. Of course, if the user’s
intent was “a capital gains worksheet with data from my brokerage account”, the
raw spreadsheet has a lot of extra detail. On the other hand, when equipped
with suitable templates Excel can come fairly close to that intent.
Other
examples of declarative programming are the query language of SQL, a parser
generator like YACC, a system for symbolic mathematics like Mathematica, and a
stub generator for remote procedure call. What they have in common is that what
you have to tell the system is closer to your intent than an ordinary program.
This makes programming faster and more reliable. It also opens up opportunities
for analysis and optimization; parallel implementations of SQL are a good
example of this.
Specifications with teeth
Specifications are
useful as documentation, but they have the same problem as all documentation:
they are often wrong. A spec is more valuable if it has teeth, that is, if you
can count on its description of the program’s behaviour. Such specs are much
more likely to pass Parnas’ coffee-stain test: the value of a spec is
proportional to the number of coffee-stains on the implementers’ copies. A type
declaration is an example of a spec with teeth.
Teeth mean
tools: the computer must check that the spec is satisfied. There are two kinds
of teeth: statically checked, and dynamically enforced by encapsulation. A
type-safe language, for example, usually is mostly statically checked, but has
dynamic checking of some casts. Static checks are better if you can get them,
since they guarantee that the program won’t crash in
Encapsulation
takes many forms. The simplest and most familiar is the sandboxing provided by
operating system processes or Java security permissions. Much more powerful is
the automatic concurrency, crash recovery, and load balancing that a
transaction monitor provides for simple sequential application programs [5].
Another example is the automatic Byzantine fault-tolerance that a replicated
state machine can provide for any deterministic program [4].
Conclusion
A general library
of software components has been a long-standing dream, but it’s unlikely to
work, because there’s no business model for it, it costs the client too much to
understand a component, and components have conflicting world views. In spite
of this discouraging conclusion, very large components do work very well,
because they have lots of clients and you use only three of them.
Two other
approaches can make software easier to write: declarative programming, and specifications
with teeth. The latter guarantee something about the behaviour of a module. The
enforcement can be done statically, as with a type checker, or dynamically, as
with transaction processing.
References
1.
Bentley, J., Knuth, D., and McIlroy, M.D., ‘A literate program,’ Comm. ACM,
vol. 29, no. 6, June 1986, pp. 471–483.
2.
Brooks, F., ‘No silver bullet,’ IEEE Computer,
vol. 20, no. 4, April 1987, pp. 10–19. Reprinted in Brooks, The mythical
man-month, 2nd ed., Addison-Wesley, 1995.
3.
Bush, W., Pincus, J., and Sielaff, D., ‘A static analyzer for finding dynamic programming errors,’ Software—Practice and Experience, vol.
30, no. 7, June 2000, pp. 775–802.
4.
Castro, M. and Liskov, B., ‘Practical Byzantine fault tolerance and proactive recovery,’ ACM Trans. Computer Systems vol. 20, no.
4, October 2002, pp. 398–461.
5.
Gray, J. and Reuter, A., Transaction processing, Morgan Kaufman, 1993.
6.
Kernighan, B. and Pike, R., The Unix programming environment, Prentice-Hall, 1984.
7.
McIlroy, M.D., ‘Mass produced software components,’
In P. Naur and B. Randell,
http://www.cs.dartmouth.edu/~doug/components.txt
9.
President’s Information Technology Advisory
Committee, information technology research: investing in our future.
http://www.ccic.gov/ac/report/
